Capturing the legendary sound that shaped countless iconic recordings from The Beatles to Taylor Swift, the WA-CX12 faithfully recreates the most coveted tube microphone in recording history. This professional large-diaphragm tube microphone meticulously replicates the original AKG C12 produced in Austria from 1953-1963, when only 2500 units were manufactured. The WA-CX12 maintains the same organic tone and pleasing top end that made the original so sought-after by world-renowned engineers and artists including Tom Petty, Michael Jackson, Alanis Morissette, and Lupe Fiasco.
At the heart of the WA-CX12 lies an edge-terminated, all-brass CK12-style capsule that stays true to the frequency response of the original production run. This capsule provides 9 polar patterns including the standard cardioid, omni, and figure-8, plus 6 intermediate patterns for maximum versatility. The circuit design remains faithful to the 1953-1963 specifications, featuring a mostly flat response until a slight dip at 2kHz followed by a gradual boost between 5-10kHz that adds the signature smoothness to vocal performances and instrumental recordings.
Premium components throughout the signal chain include a 12AY7 vacuum tube for added warmth, a custom TAB-Funkenwerk (AMI) USA Output Transformer with large-core German laminations, and high-quality capacitors for optimal signal transfer. The PCB board features no solder mask construction for the lowest possible noise floor, while the ultra-durable nickel-plated brass body houses all components. Each WA-CX12 comes complete with a custom tweed carrying case, wood mic case, premium Gotham 7-pin cable, IEC cable, shockmount, and external power supply, with every unit hand-inspected in Austin, Texas by experienced musicians and engineers.
- Custom Edge Terminated, All-Brass Vintage CK12-Style Capsule
- Custom TAB-Funkenwerk (AMI) USA Output Transformer
- Premium 12AY7 Vacuum Tube
- Premium Capacitors
- Polar Patterns: 9 Patterns - Cardioid, Omnidirectional, Figure-8, + 6 additional mixed patterns
- Max SPL: 149dB
- Frequency Response: 30Hz-20kHz
- Output Impedance: 200 Ohms
- Signal-To-Noise Ratio: 73dB
- EIN / Self-Noise: 32dBA
- Total Weight: 17 Lbs, Mic Only: 2lbs 7oz
- Mic Dimensions: 11 ⅝” x 2” (29.5cm x 5cm)
- Includes Custom Tweed Carrying Case, External IEC Grounded PSU, IEC Power Cable, Premium Gotham 5 Meter 7-Pin Tube Microphone Cable, Wood Microphone Box, Shockmount
