UDO Audio Super 8 16-Voice Polyphonic Bi-Timbral Analog-Hybrid Synthesiser
UDO-SUPER8WHT
$5299
$3999
Express post
Anywhere Australia wide*
The Super 8 represents UDO Audio’s latest evolution in analog-hybrid synthesis, positioning itself as the perfect middle ground between portability and professional power. This 16-voice polyphonic synthesiser features dual independent binaural signal chains, each capable of producing unique timbres with their own dedicated effects processing. The instrument’s bitimbral architecture allows for sophisticated sound layering, splitting, and sequencing operations that can be accessed through intuitive single-control commands.
At its heart, the Super 8 utilises complex FPGA digital oscillators paired with an entirely analog signal path to the outputs, creating a hybrid approach that captures the best of both worlds. The synthesiser offers extensive sound-shaping capabilities including wave morphing, cross and ring modulation, plus bi-directional sync functions. With 32 interchangeable waveforms and comprehensive modulation options, the tonal palette extends well beyond traditional analog boundaries while maintaining that coveted analog character.
The performance-focused design centres around a 61-note semi-weighted keyboard with polyphonic aftertouch, complemented by dedicated left-hand performance controls for real-time expression. Storage capacity includes 256 performance and patch slots alongside 16 built-in sequences, providing ample space for both preset exploration and original programming. The Super 8’s true-stereo binaural signal path, powered by dual FPGAs and twin effects processors, ensures rich spatial imaging while maintaining the road-friendly form factor that made its smaller sibling so popular with touring musicians.
- 16 voices (8 voice in binaural mode)
- Bi-timbral
- Analog-hybrid
- 61 note semi-weighted polyphonic aftertouch keybed
- High quality control elements
- FPGA-based super waveform oscillator (DDS 1) with a centroid and six sister oscillators, super modes, and wave morphing capabilities.
- High sample rate FPGA-based oscillator (DDS 2) with LFO, ring modulation modes, and sub-oscillator options; can sync to DDS 1.
- Oscillator waveshapes include sine, sawtooth, square, triangle, noise, and user-updatable complex waveforms.
- Mixer adjusts balance between DDS 1 and DDS 2 audio signals; shift mode converts balance control to stereo panning.
- Voltage Controlled Filter with 4-pole analog low-pass and 1-pole high-pass filters, two overdrive settings, and keyboard tracking.
- Analog VCA with velocity sensitivity, modulated by ENV 2, LFO 1, and DDS 2.
- Envelopes: ENV 1 (6-stage with loop mode), ENV 2 (5-stage), ENV 3 (3-stage for VCA modulation).
- LFO 1 offers modulating capabilities as an LFO, third oscillator, or drone; includes multiple waveforms and sync options.
- DDS modulators for pitch, super modes, wave morphing, pulse-width control, and modulation between DDS 1 and DDS 2.
- Stereo chorus and delay effects per layer, both modulatable and including a delay freeze function for looping.
- Performance Control Section with a two-axis bender, variable portamento, and an octave selector; LFO 2 supports detailed modulation controls.
- Expressive Controls feature a 61-note, semi-weighted keyboard with aftertouch and future MPE support.
- Overarching Controls include volume, tempo, detune, hold modes, and layer selection with single, dual, and split keyboard modes.
- Modulation Matrix with an 8x8 grid, up to 25 additional modulation destinations via direct mapping.
- Voice Assign Modes offering four selection options and eight unison modes for diverse voice stacking and filter separations.
- Binaural Option for selecting between stereo or mono voices, with a control to disable binaural output.
- Arpeggiator & Sequencer with MIDI-syncable functions, multi-mode arpeggiation, a 64-step sequencer, and adjustable swing settings.
- Memory & File Management for storing and backing up performances, patches, waveforms, and sequences; supports USB updates.
- Comprehensive connections including worldwide AC power, MIDI ports, multiple pedal inputs, stereo outputs, and headphone jacks.
