The Suhr Rufus Fuzz Guitar Effects Pedal brings the raw power of vintage fuzz tones with the responsive dynamics of a tube amplifier. This versatile pedal captures everything from the legendary sounds of The Fillmore East in '69 through to the aggressive, mid‐scoped characteristics of the Grunge era. The Rufus stands out with its ability to work equally well with both guitars and basses, ensuring your bottom‐end remains intact while delivering rich fuzz textures.
At the heart of the Rufus lies Suhr's innovative Multi‐Function Technology mf(x), which allows seamless switching between Normal and Fat modes during performance by simply holding down the footswitch. The pedal features built‐in memory that recalls your last mode selection, plus a comprehensive 3‐Band EQ for precise tone shaping without compromising your existing rig's sound. True Bypass switching via relay ensures your signal remains pristine when the effect is disengaged, while producing minimal popping during switching.
Advanced features include an FX Link connector for external switching control and remote operation, plus a sophisticated Low Battery Monitor that alerts users to low battery conditions. The monitor automatically switches the pedal to True Bypass if battery voltage drops too low for proper circuit operation, ensuring reliable performance during critical moments on stage or in the studio.
- Input Impedance: 5k Ohm
- Output Impedance: 10k Ohm
- Power Connector: 9vdc, Center Negative, 2.1mm X 5.5mm
- Operating Voltage: 9vdc
- Maximum Voltage: 18vdc
- Reverse Battery Protection: Yes
- Over Voltage Protection: Yes
- Current Consumption: 9ma
- Estimated Battery Life: Approximately 60 Hours Of Continuous Use
- Dimensions: 2.5"(W) X 4.5"(D) X 1.25"(H)
- Weight: 0.35 kg
- FX Link Connector: 1/8" Stereo
- FX Link Max Voltage: 3.3vdc
- Shield → Tip: Activate Green (Normal) Mode
- Shield → Ring: Activate Red (Fat) Mode
- Rohs Compliant: Yes
- Agency Approvals: N/A
