- Maximum input and output gain: 21 dBu
- Input impedance: 21 kΩ
- Output impedance: 100 Ω
- Common mode rejection (1 kHz): > 80 dB
- Frequency range (-3 dB): 10 Hz -100 kHz
- THD + N (0 dBu, 10 Hz – 22 kHz): -90 dB
- Crosstalk (1 kHz): -90 dB
- Noise (A-weighted): -97 dBu
- Dynamic range: 118 dB
- Operating voltage for analog audio: 15 V
- Operating voltage for relays and LEDs: 12 V
- Mains voltage (selectable): 230 V AC / 50; 115 V AC / 60 Hz
- Fuse for 230 V: T 200 mA
- Fuse for 115 V: T 400 mA
- Power consumption: max. 15 W
- 482 x 44 x 237 mm
- Unit weight: 3.3 kg
- Shipping weight (incl. packaging): 4.45 kg
