• Output Impedance XLR connector: 200 Ω
  • 6.35 mm (1/4") connector: 50 Ω
  • Audio Output Level
  • Ref. ±33 kHz deviation with 1 kHz tone
  • XLR connector: –27 dBV (into 100 kΩ load)
  • 6.35 mm (1/4") connector: –13 dBV (into 100 kΩ load)
  • RF Sensitivity -105 dBm for 12 dB SINAD, typical
  • Image Rejection >50 dB, typical
  • Dimensions BLX4: 40 mm X 188 mm X 103 mm (H x W x D)
  • Weight BLX4: 241 g (8.5 oz.)
  • Housing Molded ABS
  • Power Requirements 12–15 V DC @ 160 mA (BLX88, 320 mA), supplied by external power supply
  • (tip positive)
