- Two analog VCOs per voice
- Continuously variable wave shape (sine, sawtooth, variable-width pulse) per oscillator
- Hard sync (oscillator 1 syncs to oscillator 2)
- Square wave sub-octave generator (oscillator 1) per voice
- Keyboard tracking on/off for each oscillator
- Front-panel FM (frequency modulation)
- Mixer: Oscillator 1 amount, Oscillator 1 sub-octave amount, Oscillator 2 amount, White noise/pink noise amount
- Four-pole, resonant, low-pass filter per voice, based on Prophet-5 Rev 4 design
- Filter can be driven into self-oscillation with the Resonance control
- Bi-polar filter envelope amount
- Two 5-stage envelope generators (ADSR + delay) with variable routing (filter, amplifier, auxiliary)
- Velocity modulation of each envelope amount
- Envelopes freely assignable to multiple modulation destinations
- Five wave shapes: triangle, sawtooth, reverse sawtooth, square, and random (sample and hold)
- Clock sync (internal or external MIDI clock)
- Freely assignable to multiple modulation destinations
- One dedicated reverb with damping, pre-delay, decay and tone
- One multi-effect with stereo delay, BBD delay, tape delay, chorus, flanger, phaser, ring mod, vintage rotating speaker, distortion, high-pass filter
- Dedicated Overdrive effect
- Vintage knob recreates the characteristics of vintage synthesizers by introducing parameter variations from voice to voice
- Aftertouch freely assignable to multiple modulation destinations
- Master clock with tap tempo
- BPM control and display
- MIDI clock sync
- Arpeggiator: Up, down, up+down, random, assign modes, syncs to MIDI clock and re-latching arpeggiation
- Polyphonic step sequencer with up to 64 steps with ties and rests
- 128 user and 128 factory
