RME DPS-2 Low Noise Power Supply for ADI-2 Series & 12V HiFi Components
RME-DPS2
$1949
Free Shipping
Anywhere Australia wide*
RME's DPS-2 linear power supply redefines clean power delivery with its innovative dual-output design and compact half-rack form factor. Built on the proven ADI-2 series chassis, this exceptional unit features two distinctly filtered outputs that cater to different power requirements. The Linear output utilises traditional DC delivery enhanced by multi-stage passive and active filtering, including a substantial 30,000 �F capacitor bank, ferrite choke, and active output filter with hybrid voltage regulation.
The second output showcases RME's proprietary �Filter technology, processing the pre-filtered Linear signal through highly efficient active filters to achieve remarkably clean DC output with mere micro-volt noise levels. This output incorporates sensor technology that measures and adapts voltage directly at the DC connector, ensuring optimal performance. Two DC sensor connection cables with lockable and non-lockable 2.1 x 5.5 mm plugs are included, though only one output can be used at a time.
The DPS-2 maintains a stable +12.0 V output at 2.5 A load with extremely low output impedance and load regulation, eliminating voltage drops under varying loads. Additional features include 2-stage HF and DC filtering on the AC mains side, plus a 60 VA audio toroidal transformer with isolation winding and magnetic tape shielding. This comprehensive approach ensures completely hum and noise-free operation in any environment, making it ideal for professional audio applications.
- Dual Filtered Outputs: Includes a traditional DC output with multi-stage passive and active filtering, and a second output with RME's proprietary ?Filter technology for exceptionally clean DC output
- Advanced Filtering: Equipped with a 30,000 ?F capacitor bank, ferrite choke, and active output filter with a hybrid voltage regulator
- Low Noise Output: Delivers clean DC output with just a few µV (micro-volts) of noise
- Sensor Technology: Measures and adapts the output voltage directly at the DC connector of the supplied DC cable for stable voltage and low impedance
- High Output Performance: Provides a stable output voltage of +12.0 V at a 2.5 A load, avoiding load-dependent voltage drops
- AC Mains Filtering: Features a 2-stage HF filter and DC filter on the AC mains side to eliminate interference noise
- Toroidal Transformer: 60 VA audio toroidal transformer with additional isolation winding and magnetic tape shielding for hum- and noise-free operation
- GND Lift Switch: Disconnects DC ground from PE (protective earth) to eliminate ground loop noise without affecting safety
- Ground Terminal: Includes a ground terminal screw connection for alternative earthing options
- Status LEDs: Two status LEDs on the front panel provide a quick overview of operating modes and error conditions (power, thermal and power overload, undervoltage, short, active output)
- AutoDark Mode: Recessed push switch enables AutoDark mode, keeping LEDs off except during error states and power-up
- Comprehensive Manual: Comes with a detailed 24-page manual with technical data, measured values, diagrams, and background information on linear and switching power supplies
- Compact Design: Fits within a half-rack width, based on the ADI-2 series housing and front panel design
- Two DC Sensor Connection Cables Included: Lockable & non-lockable DC plug 2.1 x 5.5 mm, (1 m)
