- Transducers:Dual 915H 15” ferrite magnet woofers; JBL 2408H-1 1.5” poly-annular diaphragm compression driver
- Updated JBL image control waveguides improve dispersion
- FEA flared port design reduces air noise and distortion
- Low-noise, low-distortion gain staging design
- Lightweight, efficient Class D amplification
- Power: 2,000 watts peak/1,000 watts RMS
- Frequency response: 43 Hz - 20 kHz @4pi (-10 dB); 54 Hz - 17 kHz @4pi (-3 dB)
- Dispersion: 90° x 50°
- Max SPL: 137.7 dB
- Crossover frequency: 1,700 Hz
- Colour LCD screen provides access to comprehensive DSP suite
- DriveRack Technology includes Automatic Feedback Suppression, system limiter and 180ms of speaker delay in 100-microsecond intervals for precise time-aligned systems
- Optimised presets for pairing full-range speakers with subwoofers
- JBL Pro Connect app allows full system control of up to 10 JBL Pro Connect app-enabled speakers and systems
- 18 mm birch cabinet with optimised bracing delivers smooth, accurate low-frequency response
- I/Os: 2 XLR balanced Combo jacks; 1 3.5mm aux; 2 XLR-M loop-through; 1 XLR-M Mix out
- Two integrated side handles
- Suspension/mounting: single 36mm pole socket, eight M10 suspension points
- Quiet fanless operation
- Ultra-low system latency: <1ms
- Net weight: 37.3 kg (82.2 lbs); gross weight: 43 kg (94.7 lbs)
- Dimensions: 1058.5 mm x 446 mm x 434 mm (41.6 in x 17.5 in x 17.1 in) (H x W x D)
- Shipping dimensions: 1110 mm x 535 mm x 535 mm (43.7 in x 21 in x 21 in) (H x W x D)
