Compact doesn't mean compromise when it comes to the HEDD TYPE 05 MK2, the smallest active monitoring solution in HEDD's professional loudspeaker range. This space–conscious monitor combines a 5" honeycomb woofer with an ultra–high–precision AMT tweeter, making it ideal for home studios, broadcast facilities, and video editing suites where real estate is at a premium.
At the heart of the TYPE 05 MK2 sits a powerful SHARC–DSP processor featuring HEDD's groundbreaking Lineariser technology, which perfects stereo imaging and depth by optimising speaker phase response. The innovative CoP (Chamber of Pressure) modes give you flexibility between two distinct sonic characters: "Closed" mode for pristine accuracy, or "Ported" mode when you need higher SPL capability with extended low–frequency response.
The MK2 series includes Desktop and Shelving filters to fine–tune the monitors for your specific studio environment, plus a remarkable Bass–Extension mode that unlocks even deeper frequency reproduction. All adjustments are made via stepped aluminium potentiometers, ensuring your settings are both precise and repeatable. Connectivity options include analogue XLR and digital AES inputs, providing professional–grade interfacing for any studio setup.
- HEDD Lineariser®, CoP, GDC, LFE, Desk and Shelf Filters
- Custom high-resolution 96 kHz / 32 Bit AD / DA converter
- 2-Way: 5" Woofer (1,5" voice coil) + HEDD AMT Tweeter
- 2x100 W ICEpower amplification (85-264 V)
- 2.500 Hz Crossover
- Frequency range: 45 Hz - 40 kHz (LFE: 38 Hz - 40 kHz)
- 112 dB SPL (sound pressure level) per pair at 1m
- Inputs: Analog (XLR / 22 k?) and Digital 2ch (AES / XLR)
- Outputs: Digital AES pass-through via XLR
- Dimensions: 308 x 180 x 245 mm
- Weight: 6.4 kg per unit
