Electro-Voice ZX1 8" 2-Way Passive Full-Range Loudspeaker (Black)

The Electro-Voice® ZX1 is the new standard of no-compromise audio performance and versatility for compact sound reinforcement. The high-tech enclosure uses injection-molded, high-impact polypropylene to make the ZX1 extremely durable. Its geometry is engineered for maximum rigidity and acoustic performance. The velocity-compensated port design overcomes the limitations of many small loudspeakers and enables exceptional low-frequency response without vent noise.

The ZX1’s long-excursion, high-output 8" woofer with a weatherized treated cone delivers smooth low-frequency performance with exceptional reliability. A sophisticated crossover network integrates it with the DH2005—a 1.25" voice-coil titanium diaphragm true compression driver—for maximum output with extended frequency response. Full-bandwidth overload protection is provided for reliable, long-term operation without audible effects.

The horn features 90° × 50° coverage with the added benefit of rotation, allowing the ZX1 to be oriented either horizontally or vertically for maximum coverage flexibility. The ZX1’s molded polymer enclosure is inherently water-resistant and includes an integrated pole mount, a pocket handle, and a wedge-angle design that allows it to be used as a stage monitor.

Features

• 2–way passive full–range composite loudspeaker
• Smooth, wide frequency response
• Ideal for mains, fills, or monitors
• Velocity-compensated port for exceptional LF
• Long-excursion weather-treated EV8L woofer
• 1.25-inch DH2005 titanium HF compression driver
• Rotatable 90° × 50° horn for flexible coverage
• Passive crossover with full-band overload protection
• High sensitivity, 123 dB maximum SPL
• Power handling: 200 W continuous, 800 W peak
• High-impact polypropylene enclosure
• Compact monitor-friendly wedge shape
• Integrated pole mount adapter and pocket handle
