• Channels (Mono + Stereo): 6 + 4
  • Auxiliarys (MON, FX, AUX): 2 Pre, 2 Post, 2 Pre/Post switchable
  • MIC GAIN (Mono / Stereo): 0 to +60 dB / +10 to +60 dB
  • LINE/CD/USB GAIN (Stereo): -10 to +20 dB
  • THD, at 1 kHz, MBW = 80 kHz
  • MIC input to Master A L/R outputs, +16 dBu, typical: < 0.005%
  • Frequency Response, -3 dB, ref. 1 kHz, any input to any Mixer output: 15 Hz to 70 kHz
  • Crosstalk, 1 kHz
  • Fader & FX/AUX/MON-Send attenuation: > 85 dB
  • Channel to Channel: < -80 dB
  • CMRR, MIC input, 1 kHz: > 80 dB
  • Input Sensitivity, all level controls in max. position MIC / LINE (Mono) / LINE (Stereo) / CD (Stereo): -74 dBu (155 µV) / -54 dBu (1.55 mV) / -34 dBu (15.5 mV) / -34 dBu (15.5 mV)
  • Maximum Level, mixing desk
  • MIC inputs: +21 dBu
  • Mono Line inputs / Stereo Line inputs: +41 dBu / +30 dBu
  • All other inputs: +22 dBu
  • All other outputs: +22 dBu
  • MIC / Insert Return: 2 ㏀ / > 3.3 ㏀
  • 2Track Return & CD In: 10 ㏀
  • All other inputs: > 15 ㏀
  • Output Impedances: Phones 47 Ω, All other outputs 75 Ω
  • Equivalent Input Noise, MIC input, A-weighted, 150 ohms: -130 dBu
  • Noise, Channel inputs to Master A L/R outputs, A-weighted
  • Master fader down: -97 dBu
  • Master fader 0 dB, Channel fader down: -91 dBu
  • Master fader 0 dB, Channel fader 0 dB, Channel gain unity: -83 dBu

Equalization

  • LO Shelving: ±15 dB / 60 Hz
  • MID Peaking, mono inputs: ±15 dB / 100 Hz to 8 kHz
  • MID Peaking, stereo inputs: ±12 dB / 2.4 kHz
  • HI Shelving: ±15 dB / 12 kHz
  • Master EQ 11-band (63, 125, 250, 400, 630, 1k, 1.6k, 2.5k, 4k, 6.3k, 12kHz): ±10 dB / Q = 1.5 to 2.5
  • Power Consumption, without lamp / with lamp: 45 W / 50 W

Filter

  • LO-CUT, mono inputs: f = 80 Hz, 18 dB/oct.
  • VOICE FILTER, mono inputs: switchable
  • FEEDBACK FILTER, MON 1/2: 70 Hz to 7 kHz, Notch, -9 dB

Effects

  • Type, effects presets: Dual stereo 24/48-bit multi effects processors, 100 Factory + 20 User, Tap-Delay
  • Remote control: Footswitch, MIDI
  • Display: 128 x 64 pixels, OLED
  • Digital Audio Interface
  • Channels: 4 In / 4 Out
  • AD/DA Conversion, Sampling Rate: 24-bit, 44.1 / 48 / 88.2 / 96 kHz
  • PC Interface: USB2.0, Female Type B
  • Supported OS: See documentation
  • MIDI Interface: 5-pin DIN connector, In / Out
  • Mixer Outputs (Relay controlled): MON 1, MON 2, MASTER A
  • Switching Mode Power Supply (µC controlled): Mains Over/Undervoltage, High Temperature
  • Phantom Power, switchable in groups: 48 V DC
  • Power Requirements (SMPS with auto range mains input): 100 V to 240 V AC, 50 Hz to 60 Hz
  • Dimensions (W x H x D, without lid), mm: 510.5 x 155 x 498.5 Rack-mount: 483.0 x 135.0 x 443.7
