• SDI Video Input: Automatically switches between SD, HD and 3G-SDI. Reclocked loop through output
  • Multi Rate Support: Auto detection of 2K, HD or standard definition inputs
  • Updates and Configuration: Via USB 2.0 high speed (480 Mb/s)
  • Ethernet: 10/100 BaseT with loop through
  • Tally: 9-pin D connector
  • SDI Compliance: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M Level B and SMPTE 425M
  • SDI Colour Space: REC 601, REC 709
  • SDI Auto Switching: Automatically selects between SD, HD and 3 Gb/s SDI
  • Video Sampling: 4:2:2 and 4:4:4
  • SDI Format Support: 525i59.94 NTSC, 625i50 PAL, 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
  • 2K Format Support: 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF
  • Internal Software Upgrade: Via included firmware updater software
  • SmartView Utility Software: Via USB or Ethernet
  • Display Element: TFT Active Matrix LCD
  • Display Resolution: 800 x 480 pixels
  • Response: < 15 ms
  • Contrast Ratio: Typically 500:1
  • Colour Depth: 16.7 Million Colours
  • Display Orientation: Displays can rotate upside down for optimum viewing angle
  • Power Supply: 12V universal power supply included with international socket adaptors for all countries
  • Power Consumption: < 20 Watts
  • Operational Voltage Range: 12V - 15V
  • Operating Temperature: 0° to 40° C (32° to 104° F)
  • Storage Temperature: -20° to 45° C (-4° to 113° F)
  • Relative Humidity: 0% to 90% non-condensing
