• SDI Video Inputs: 1
  • SDI Video Outputs: 2
  • SDI Monitor Outputs: 1
  • SDI Rates: 270Mb, 1.5G, 3G, 6G
  • HDMI 2.0 Video Inputs: 1
  • HDMI 2.0 Video Outputs: 1
  • Built in Speaker: Mono
  • Audio Output: 1 x 6.35 mm headphone jack
  • Screen: 2.2 inch LCD
  • Timecode Connections: 1 x BNC In, 1 x BNC Out
  • Reference Connections: 1 x BNC In, 1 x BNC Out (Tri-Sync or Black Burst)
  • SDI Audio Inputs: 16 channels embedded audio
  • SDI Audio Outputs: 16 channels embedded audio
  • HDMI Audio Inputs: 8 channels embedded audio
  • HDMI Audio Outputs: 8 channels embedded audio
  • Remote Control: 1 x RS-422 In, 1 x RS-422 Out
  • Recorder Configuration: Via user interface or Blackmagic HyperDeck Ethernet Protocol
  • Ethernet: 1Gb/s
  • Computer Interface: 1 x USB Type-C 3.0 (up to 5Gb/s) for external drive recording, webcam out, software configuration and updates
  • SD Video Standards: 525i59.94 NTSC, 625i50 PAL
  • Audio Sampling: Television standard 24‑bit, 48 kHz sample rate
  • Video Sampling: 4:2:2 YUV
  • Colour Precision: 10-bit
  • Multi Rate Support: Auto detection of SD, HD and 6G-SDI
