- Power Rating: 60 watts
- Frequency response: 60Hz-18kHz
- Speaker: 8" [200mm] twin-cone system
- Two channels
- Phantom power: 24v [channel 2]
- Dimensions:
- Height: 10.24"
- Width: 13.00"
- Depth: 9.06"
- Weight: 8kg
- Input for a 1/4" jack plug
- High/Low switch to adjust input sensitivity High impedance instruments with a piezoelectric pick-up, Low for instruments with active pre-amplifiers and magnetic sound pick-ups
- Clipping indicator
- Gain input level control
- Colour mid-range contour filter
- Bass tone control for low frequencies
- Middle tone control for mid-range frequencies
- Treble tone control for high frequencies
- Input XLR combination with an input for a 1/4" jack plug and XLR male socket
- Line/Mic switch adjusts input sensitivity
- Line sources with line level, instruments with active preamplifiers and magnetic sound pick-ups,
- Mic: symmetrical microphone input with 30V phantom source
- Clipping indicator
- Gain input level control
- Bass tone control for low frequencies
- Treble tone control for high frequencies
- Eff. Pan panorama control is for distributing the effects between the channels
- Select push button to choose between four effects, indicated by the LEDs between return and master (pos.1 warm hall, pos. 2 bright hall reverb, pos. 3 chorus with reverb, pos. 4 flanger)
- Return level control for internal effects
- Power indicator light
- Master level control
- Headphone output
- Tuner output
- Line out
- DI-out XLR output
- Send output for an external device
- Return input for effects or CD player
- F/S connection for a double foot switch
- Power combined mains switch
